Base Station Antenna

Hybrid-beam Antenna

Pol
5X Pol
Frequency Range (MHz)
1710-2690/1710-2690/1710-2690/1710-2690/690-960
Horizontal Beamwidth
32/32/32/32/65
Gain (dBi)
17.7/17.5/17.7/17.5/14.5
DETAILS
Pol
5X Pol
Frequency Range (MHz)
1710-2690/1710-2690/1710-2690/1710-2690/690-960
Horizontal Beamwidth
32/32/32/32/65
Gain (dBi)
18.4/18.1/18.4/18.1/15.5
DETAILS
Pol
5X Pol
Frequency Range (MHz)
1710-2690/1710-2690/1710-2690/1710-2690/690-960
Horizontal Beamwidth
32/32/32/32/65
Gain (dBi)
18.4/18.1/18.4/18.1/15.5
DETAILS
Pol
7X Pol
Frequency Range (MHz)
1695-2690/1695-2690/1695-2690/1695-2690/690-960/1695-2690/1695-2690
Horizontal Beamwidth
32/32/32/32/65/65/65
Gain (dBi)
18.9/18.4/18.9/18.4/15.7/16.4/16.4
DETAILS
Pol
5X Pol
Frequency Range (MHz)
1710-2690/1710-2690/690-960/1695-2690/1695-2690
Horizontal Beamwidth
32/32/65/65/65
Gain (dBi)
19.2/19.2/16.5/17.7/17.7
DETAILS
Pol
4X Pol
Frequency Range (MHz)
1710-2690/1710-2690/1710-2690/1710-2690/690-960/690-960
Horizontal Beamwidth
32/32/32/32/65/65
Gain (dBi)
18.6/18.5/18.6/18.5/15.3/15.3
DETAILS
Pol
6X Pol
Frequency Range (MHz)
1710-2690/1710-2690/1710-2690/1710-2690/690-960/690-960
Horizontal Beamwidth
32/32/32/32/65/65
Gain (dBi)
18.6/18.5/18.6/18.5/15.3/15.3
DETAILS
Pol
8X Pol
Frequency Range (MHz)
1710-2690/1710-2690/1710-2690/1710-2690/690-960/690-960/1695-2690/1695-2690
Horizontal Beamwidth
32/32/32/32/65/65/65/65
Gain (dBi)
18.5/18.2/18.5/18.2/15.3/15.3/16.0/16.3
DETAILS
Pol
10X Pol
Frequency Range (MHz)
1710-2690/1710-2690/1710-2690/1710-2690/1710-2690/1710-2690/1710-2690/1710-2690/690-960/690-960
Horizontal Beamwidth
32/32/32/32/32/32/32/32/65/65
Gain (dBi)
18.0/17.7/18.0/17.7/18.0/17.7/18.0/17.7/15.1/15.1
DETAILS
Pol
10X Pol
Frequency Range (MHz)
1710-2170/1710-2170/1710-2170/1710-2170/2490-2690/2490-2690/2490-2690/2490-2690/690-960/690-960
Horizontal Beamwidth
32/32/32/32/32/32/32/32/65/65
Gain (dBi)
18.0/17.5/18.0/17.5/18.0/17.7/18.0/17.7/15.2/15.2
DETAILS
Pol
6X Pol
Frequency Range (MHz)
1710-2690/1710-2690/1710-2690/1710-2690/690-960/690-960
Horizontal Beamwidth
32/32/32/32/65/65
Gain (dBi)
20.0/19.9/20.0/19.9/16.3/16.3
DETAILS
