Base Station Antenna

Penta-band Antenna-10 Ports

Pol
5X Pol
Frequency Range (MHz)
694-960/1710-2170/2490-2690/1710-2170/2490-2690
Horizontal Beamwidth
65
Gain (dBi)
15.0/17.0/17.2/17.0/17.2
DETAILS
Pol
5X Pol
Frequency Range (MHz)
690-960/1695-2690/1695-2690/1695-2690/1695-2690
Horizontal Beamwidth
65
Gain (dBi)
14.7/15.9/15.8/15.9/15.8
DETAILS
Pol
5X Pol
Frequency Range (MHz)
690-960/690-960/1427-2690/1427-2690/1695-2690
Horizontal Beamwidth
65
Gain (dBi)
14.3/14.3/17.9/17.9/17.6
DETAILS
Pol
5X Pol
Frequency Range (MHz)
690-960/1695-2690/1695-2690/1695-2690/1695-2690
Horizontal Beamwidth
65
Gain (dBi)
16.0/16.6/16.4/16.6/16.4
DETAILS
Pol
5X Pol
Frequency Range (MHz)
690-960/1695-2690/1695-2690/1695-2690/1695-2690
Horizontal Beamwidth
65
Gain (dBi)
16.0/16.6/16.4/16.6/16.4
DETAILS
Pol
5X Pol
Frequency Range (MHz)
690-960/690-960/1427-2690/1427-2690/1695-2690
Horizontal Beamwidth
65
Gain (dBi)
15.7/15.7/16.1/16.1/16.6
DETAILS
Pol
5X Pol
Frequency Range (MHz)
694-960/1695-2690/1695-2690/1695-2690/1695-2690
Horizontal Beamwidth
65
Gain (dBi)
16.7/17.4/17.6/17.4/17.6
DETAILS
Pol
5X Pol
Frequency Range (MHz)
1710-2690/1710-2170/2490-2690/1710-2170/2490-2690
Horizontal Beamwidth
65
Gain (dBi)
18.0/17.0/17.5/17.0/17.5
DETAILS
