Base Station Antenna

Multi-band Antenna-16 Ports

Pol
8X Pol
Frequency Range (MHz)
694-960/694-960/1427-2690/1695-2690/1695-2690/1695-2690/1695-2690/1695-2690
Horizontal Beamwidth
65
Gain (dBi)
16.6/16.6/17.8/17.6/17.2/17.9/17.6/17.2
DETAILS
Pol
8X Pol
Frequency Range (MHz)
2x6904-960/2x1695-2690/2x1710-2170/2x2490-2690
Horizontal Beamwidth
65
Gain (dBi)
14.5/14.5/17.6/17.6/17.3/17.3/17.5/17.5
DETAILS
Pol
8X Pol
Frequency Range (MHz)
694-960/694-960/1695-2690/1695-2690/1695-2690/1695-2690/1695-2690/1695-2690
Horizontal Beamwidth
65
Gain (dBi)
14.2/14.2/14.7/14.5/15.8/15.6/14.7/14.5
DETAILS
Pol
8X Pol
Frequency Range (MHz)
690-960/690-960/1427-2690/1427-2690/1710-2170/1710-2170/2490-2690/2490-2690
Horizontal Beamwidth
65
Gain (dBi)
15.5/15.5/17.9/17.9/17.4/17.4/17.9/17.9
DETAILS
Pol
8X Pol
Frequency Range (MHz)
2x690-960/2x1427-2690/2x1710-2170/2x2490-2690
Horizontal Beamwidth
65
Gain (dBi)
15.0/15.0/17.7/17.7/17.4/17.4/17.5/17.5
DETAILS
Pol
8X Pol
Frequency Range (MHz)
690-960/690-960/1427-2690/1427-2690/1710-2170/1710-2170/2490-2690/2490-2690
Horizontal Beamwidth
65
Gain (dBi)
16.5/16.5/17.3/17.3/17.3/17.3/17.0/17.0
DETAILS
